Industrial Dual-Joystick Wireless Remote Controller | Joystick with Built-in Digital Signals, Fully Customizable Structure & Functions

Description

This portable dual-joystick industrial remote supports in-depth personalized customization. Push-button digital switches can be mounted on top of each joystick to transmit joystick operation and button signals simultaneously. A single joystick integrates both proportional speed regulation and digital point control, removing the need for an extra button panel and delivering a neater, more compact body layout.

1. Multi-Functional Custom Joysticks with Expandable Digital Signals
Equipped with two standard proportional main joysticks. Single or dual digital point switches can be installed on joystick heads on demand. Forward/backward and left/right movements feature stepless proportional speed control. The built-in joystick buttons can be assigned to digital commands such as lights, horns and jog operation. One joystick transmits one set of proportional signal plus digital signal at the same time.

2. Optional Joystick Types
Multiple joystick specifications are interchangeable: universal single-axis joysticks, dual-axis proportional joysticks, self-locking joysticks, spring-return joysticks, etc. Joystick travel, damping feel and operating force are adjustable to match equipment operating habits, suitable for light and heavy load operation demands.

3. Fully Programmable Body Buttons & Switches
All toggle switches and push points on the controller body are programmable. Functions including high/low speed switching, lock/unlock, ignition and flameout can be assigned as required.

4. Customizable Appearance & Structure
Customizable options include carrying frame, shoulder harness, housing color, screen-printed panel text and OEM LOGO labeling. It supports universal 12V/24V power supply. Wiring harness connectors and output protocols are compatible with original vehicle control systems for direct matching and installation upon delivery.
